Drawworks

Reliable Mechanical, DC Drive & AC Variable Frequency Drawworks for Drilling Rigs

---

Product Introduction

The Drawworks is the core power transmission and hoisting equipment of a drilling rig, responsible for lifting, lowering, and controlling drill strings, casing, tubing, and other heavy loads throughout drilling operations.

TSS-TUP supplies high-performance Mechanical Drawworks, DC Drive Drawworks, and AC Variable Frequency (VFD) Drawworks manufactured to API standards for land drilling rigs, offshore platforms, workover rigs, geothermal drilling, and mining applications.

Designed for durability, safety, and efficient operation, our drawworks systems deliver reliable performance under demanding drilling environments while reducing maintenance costs and operational downtime.

---

Product Features

Heavy-Duty Structural Design

High-strength welded steel construction provides outstanding load capacity and long service life.

Multiple Drive Options

Available in Mechanical Drive, DC Drive, and AC Variable Frequency Drive configurations to meet different drilling requirements.

Precision Transmission System

Optimized gears, shafts, and braking systems ensure smooth lifting performance and stable torque transmission.

Reliable Braking Performance

Hydraulic disc braking systems provide safe operation under heavy loads and emergency conditions.

Low Maintenance Design

Advanced lubrication systems and precision machining reduce component wear and extend maintenance intervals.

OEM Replacement Capability

Complete replacement solutions for existing drilling rigs and legacy equipment.

---

Technical Specifications

Typical specifications include:

• Mechanical Drive Models
• DC Drive Models
• AC Variable Frequency Drive Models
• Rated Load: 400–700 kN
• Drilling Depth: Up to 6,000 m
• Hydraulic Disc Brake System
• High Strength Steel Structure
• API Standard Manufacturing
• Custom Engineering Available

Specifications can be customized according to customer requirements.

---

Available Models

Mechanical Drive

• JC40
• JC50
• JC70

DC Drive

• JC40D
• JC50D
• JC70D

AC Variable Frequency Drive

• JC40DB
• JC50DB
• JC70DB

Customized configurations are available.

---

Applications

Suitable for:

• Oil & Gas Drilling Rigs
• Onshore Drilling
• Offshore Drilling
• Workover Rigs
• Deep Well Drilling
• HPHT Drilling
• Geothermal Drilling
• Mining Drilling Projects

---

Why Choose TSS-TUP

TSS-TUP provides complete drawworks solutions backed by engineering expertise and precision manufacturing.

Our advantages include:

✔ API Standard Manufacturing

✔ Mechanical, DC & AC Drive Solutions

✔ Precision Machining

✔ Strict Quality Inspection

✔ OEM Replacement Manufacturing

✔ Reverse Engineering Support

✔ Fast Global Delivery

✔ Technical Engineering Assistance

---

OEM & Custom Manufacturing

Besides standard drawworks, we also provide:

• OEM Replacement Drawworks
• Custom Drive Systems
• Reverse Engineered Components
• Manufacturing from Drawings
• Spare Parts Manufacturing
• Heavy-Duty Upgrades
• Legacy Equipment Support

---

Quality Control

Every drawworks system undergoes comprehensive quality inspection before shipment.

Inspection includes:

• Material Verification
• Gear Inspection
• Shaft Inspection
• Brake System Inspection
• Welding Inspection
• Assembly Inspection
• Performance Testing
• Final Quality Inspection

Each product is professionally packed for international transportation.

---

FAQ

Can you manufacture according to customer drawings?

Yes. We manufacture according to drawings, specifications, or physical samples.

Do you supply complete drawworks systems?

Yes. Both complete drawworks units and replacement spare parts are available.

Which drive systems are available?

Mechanical Drive, DC Drive, and AC Variable Frequency Drive.

Can you manufacture replacement parts for discontinued equipment?

Yes. We specialize in reverse engineering and OEM replacement manufacturing.

Do you support worldwide shipping?

Yes. We provide global logistics, export documentation, and technical support.

---

Request a Quote

Looking for reliable Drawworks or replacement drilling rig components?

Contact TSS-TUP today for competitive pricing, OEM manufacturing, engineering support, and worldwide delivery.

Contact Us
