Product Introduction

The API Rotary Table is a key component of the drilling rig rotary system, providing reliable torque transmission and supporting drill string rotation during drilling operations. Designed for demanding oilfield applications, rotary tables must deliver stable performance under high loads, continuous rotation, and harsh operating environments.

Our ZP Series Rotary Tables are manufactured for land drilling rigs, offshore drilling platforms, geothermal drilling, mining exploration and workover operations. Built with precision-machined gears, high-strength alloy steel structures and heavy-duty bearing systems, they offer superior torque capacity, long service life and dependable operation.

Available from ZP175 to ZP650Y, our rotary tables are suitable for drilling projects ranging from shallow wells to ultra-deep drilling applications.

---

Product Features

High Torque Transmission

Optimized gear design provides smooth power transmission and excellent torque capacity for demanding drilling conditions.

Heavy-Duty Gearbox

Heat-treated alloy steel gears offer superior wear resistance and extended operating life under continuous heavy-duty service.

Precision Bearing System

High-capacity roller bearings improve rotational accuracy while reducing vibration and maintenance requirements.

Advanced Sealing Design

Multi-stage sealing system effectively prevents drilling fluid contamination and lubricant leakage.

Reinforced Structural Frame

High-strength steel construction ensures excellent rigidity, load distribution and fatigue resistance.

Multiple Model Options

Available in ZP175, ZP205, ZP275, ZP375, ZP375Z, ZP495 and ZP650Y configurations for various drilling rig capacities.

Technical Specifications

Model	Table Opening	Maximum Torque	Hook Load Capacity	Application
ZP175	17-1/2"	25 kN·m	1350 kN	Water Well & Workover
ZP205	20-3/4"	45 kN·m	2250 kN	Land Drilling
ZP275	27-3/4"	85 kN·m	3150 kN	Deep Drilling
ZP375	37-1/2"	150 kN·m	5000 kN	Heavy Duty Drilling
ZP375Z	37-1/2"	160 kN·m	5000 kN	Top Drive Compatible
ZP495	49-1/2"	250 kN·m	6750 kN	Offshore Drilling
ZP650Y	65"	400 kN·m	10000 kN	Ultra Deep Drilling

Available Models

• ZP175 Rotary Table
• ZP205 Rotary Table
• ZP275 Rotary Table
• ZP375 Rotary Table
• ZP375Z Rotary Table
• ZP495 Rotary Table
• ZP650Y Rotary Table

---

Applications

Our API rotary tables are widely used in:

• Oil & Gas Drilling Rigs
• Onshore Drilling Operations
• Offshore Drilling Platforms
• Geothermal Drilling
• Mining Exploration
• Directional Drilling
• Workover Rigs
• Water Well Drilling
• HPHT Drilling Projects

---

Why Choose TSS-TUP

• API standard manufacturing
• High-strength alloy steel construction
• Precision-machined gear transmission
• Heavy-duty bearing assemblies
• Excellent torque performance
• Long operating service life
• OEM replacement solutions
• Global technical support
• Fast worldwide delivery
• Strict quality inspection

---

OEM & Custom Manufacturing

TSS-TUP provides complete OEM and custom manufacturing services for rotary tables, including:

• Custom table openings
• Customized torque capacity
• Special gear configurations
• Heavy-duty bearing upgrades
• Drawing-based manufacturing
• Sample-based production
• OEM replacement manufacturing
• Replacement for obsolete rotary tables

---

Quality Control

Every rotary table undergoes comprehensive quality inspection before shipment, including:

• Raw material verification
• Precision machining inspection
• Gear hardness testing
• Bearing inspection
• Assembly accuracy verification
• Dynamic operation testing
• Surface coating inspection
• Final factory quality inspection

---

FAQ

What standards do your rotary tables comply with?

Our rotary tables are manufactured according to applicable API standards and industry quality requirements.

Which rotary table models are available?

We supply ZP175, ZP205, ZP275, ZP375, ZP375Z, ZP495 and ZP650Y models.

Can you manufacture OEM replacement rotary tables?

Yes. We provide OEM replacement rotary tables based on customer drawings, specifications or samples.

Do you supply rotary table spare parts?

Yes. We supply gears, bearings, master bushings, drive bushings, shafts, seal kits and other replacement components.

Are your rotary tables suitable for offshore drilling?

Yes. Offshore-duty configurations with enhanced corrosion protection are available for demanding drilling environments.

---

Request a Quote

Looking for reliable API Rotary Tables or replacement rotary system equipment?

Contact TSS-TUP today for technical consultation, competitive pricing and fast worldwide delivery. Our engineering team can recommend the most suitable rotary table solution based on your drilling rig specifications.
